Valco Cincinnati 41
Initial Setup
Introduction
This section contains procedures for initial setup of the control. It may be helpful to refer to the flowcharts pro-
vided in the “Menus” section of this manual. The flowcharts are located as follows:
• Primary menu screens—Figure 14 (page 26)
• Level-1 menu screens—Figure 17 (page 29)
• Level-2 menu screens—Figure 18 (page 32)
• Level-3 menu screens—Figure 19 (page 34)
• Level-4 menu screens—Figure 20 (page 36)
• Level-5 menu screens—Figure 21 (page 38)
Initial Setup
To conduct initial setup of the control, complete each of the following procedures.
Disable Glue Valves for All Channels
To disable glue valves for all channels, follow these steps:
1. Place channel toggle switches in center position (“0”) to prevent gluing during setup procedure.
Specify Inches or Millimeters
To specify inches or millimeters, follow these steps:
1. Press the “CONFIG” button on the main screen. (The level-1 menu screen displays.)
2. Press the “MORE” button in the level-1 menu screen.
3. Press the MORE button in menu screens 2, 3 and 4. The level-5 menu screen displays.
4. Press the “IN/METRIC” button. The inch/metric screen displays.
5. Press either the “INCH MODE” button or the “METRIC MODE” button. (The arrow points toward the
mode that you have selected).
Note! When the “inch mode” is selected, all linear measurements are displayed and entered in inches, using
four digits—two of which are decimal places (example: 10.00 = 10 inches). Pressure is displayed in
pounds per square inch (psi). When the “metric mode” is selected, all linear measurements are
displayed and entered in millimeters, using four digits
(example: 1000 = 1000 millimeters). Pressure is displayed in bar.
Note! Small errors (0.04 inch or 1mm) will result in parameters when switching between inch and metric
modes.
6. Press the “EXIT” button to return to the level-5 menu screen.
