Valcom V-2006A User Manual

2 947100
VoIP (Voice-over-Internet-Protocol)
Adapters
• Valcom’s VoIP adapters provide loudspeaker
paging through the client’s LAN/WAN.
• VIP-800, Networked Audio Port, enables voice
access over an IP-based LAN/WAN. Other VIP-
800(s) will allow page zone extensions anywhere
else on the network.
• VIP-810, Networked Station Port, connects to an
FXO port, loop start trunk port, or dedicated
analog telephone terminal device, and is connected
to an IP-based LAN/WAN.
• VIP-820, Networked Trunk Port, allows a PBX
system device or IP telephone adapter to be
connected to a managed IP-based LAN/WAN.
The PBX system device or IP telephone adapter
must provide an open loop disconnect signal.
• UP to 99 zones are possible using a VIP-800 unit
per zone for audio output.
Dimensions
V-1094A: 4.44"H x 2.75"W x 2.88"D
(11.28cm x 6.99cm x 7.32cm)
V-2000A: 7.75"H x 5.8"W x 2.6"D
(19.69cm x 14.73cm x 6.6cm)
V-2001A: 7.09"H x 9.0"W x 2.4"D
(18.0cm x 22.86cm x 6.1cm)
V-2003A: 7.13"H x 10.00"W x 3.00"D
(18.1cm x 25.4cm x 7.62cm)
V-2006A: 10.9"H x 13.00"W x 2.69"D
(27.7cm x 33.0cm x 6.83cm)
V-2924A: 17.5"H x 10.3"W x 3.06"D
(44.45cm x 26.26cm x 7.77cm)
V-2925A: 17.5"H x 8.37"W x 3.06"D
(44.45cm x 21.26cm x 7.77cm)
V-2926: 5.3"H x 3.0"W x 1.1"D
(13.46cm x 7.620cm x 2.79cm)
V-2928: 5.3"H x 3.0"W x 1.1"D
(13.46cm x 7.620cm x 2.79cm)
V-1109RTVA: 7.13"H x 5.9"W x 2.13"D
(18.11cm x 14.99cm x 5.41cm)
VIP-800: 1.88”H x 5.50”Wx 4.15”D
(4.78cm x 13.97cm x 10.54cm)
VIP-810: 1.88”H x 5.50”Wx 4.15”D
(4.78cm x 13.97cm x 10.54cm)
VIP-820: 1.88”H x 5.50”Wx 4.15”D
(4.78cm x 13.97cm x 10.54cm)
Environment
Control Units:
Temperature 0 to +40 degrees C
Humidity 0-85% non-precipitating
Inside Speakers:
Temperature -20 to +55 degrees C
Humidity 0-95% non-Precipitating
Horn Speakers:
Temperature -20 to +55 degrees C
Humidity 0-95% non-precipitating
Control Unit Power Requirements
Table 1
Control Unit "A" Battery
"B" Battery
VPU
V-1094A - 50 mA -1
V-1101A 50 mA 100 mA -3
V-2000A Supplies 600 milliamps, filtered +12
V-2001A Supplies 1 Amp, filtered +20
V-2003A Supplies 1.Amp, filtered +20
V-2006A Supplies 1.5 Amp, filtered +30
V-2924A/V-2925A A. C. Line Powered 0
V-1109RTVA
60 mA 250 mA -6
VIP- 800/810/820
Power Supply Included 0
Notes for Table 1:
"A" Battery: -21.5 to -26VDC filtered "talk" battery
"B" Battery: -21.5 to -25VDC unfiltered "signal" battery
Filtered "A" battery may be used as both "A" battery
and "B" battery.
Unfiltered "B" battery may not
be used in place of
filtered "A" battery.
VPU = Valcom Power Unit.

Valcom V-2006A Specifications

General

Brand	Valcom
Model	V-2006A
Category	Microphone
Language	English
