2
Parts List
37
38
35
36
31a
31b
15
Dimensions
Dimensions,
mm
A B C D E F G
Weight Max Fuel
Load
Anthracite
Minimum Flue
Draught
Ridlington
607 566 283 485 363 140 164 90 Kg 8.64 Kg 12 Pa
0.048 In Wg
Ventilation Requirement: 21.5cm
2
unrestricted free air
Key To Dimensions
A—Height
B—Width
C—Centreline of Flue
D—Height To Centre of Rear Flue
E—Depth
F—Rear to Centre of Top Flue
G—Flue Diameter
Output Output kW
Ridlington
Cycle
Hours
Anthracite
8.42 4
Wood Logs
8.9 1
Coal
6.5 4
Peat
8.38 2
Closed Fire Briquettes
8.64 4
Dimensions may vary slightly, the manufacturers reserve the right to adjust them without notice.
Outputs stated are under ideal test conditions. Variations will occur due to installation, atmospheric
conditions and fuel quality.
