8
Model Code Page
10. General
1. 12. 1986
205--865 110 2
3. Tractor model
At the top of each page it is indicated for which tractor the page is valid.
4. Code designation
Three---digit code designations are used to separate the different document groups for the respective components. The same
code is also used in the Time list as a reference to the text in this manual. The code designation numbers appear in the box at
thetopofthepageandalsointheheadings.
Example: Code 410
--- Group: power transmission (4)
--- Component: clutch (41)
--- Document group: general (410)
5. Page numbers
The instructions for all components are numbered in consecutive order in the right---hand box at the top of the page. The page
numbers begin with page 1 for each component.
41. Clutch
15. 5. 1993
Model Code
Page
205---665 410 1
8. 11. 1990
6. Date
At the top of each page there are two boxes for dates. In a case of revised issue, the date of the earlier issue is printed in the
crossed---over box and and the date of the current issue is printed in the proper date box.
7. Additions and amendments of the service manual
New and up---dated pages will be continuously added to the service manual. The new pages should be inserted as indicated by
the code: the first digit (also the first digit on the index leaf) indicates the group:
--- the two first digits indicate the component or sub---group.
--- the third digit indicates the document group for the respective components
--- the page number indicates the definite position of the page within the service manual.
If there are two pages with the same code and page number, it is the page with the later date in the date box and the old date
in the crossed---over box which is valid or which is the current page.
When an entirely new set of repair instructions is issued, it will be accompanied by instruct ions on where the pages should be
inserted in the file.
