Track widths (LS models)
Rear (7.)
Track width
420/85R38 1610, 1715, 1810, 1910, 2010, 2115
18.4R38, 460/85R38 1610, 1715, 1810, 1910, 2010
20.8R38, 520/70R38, 520/85R38, 480/80R42 1715, 1810, 1910, 2010
540/65R38, 580/70R38, 600/65R38 1715, 1810, 1910
650/60R38, 650/65R38 1810, 1910
270/95R48 1500, 1520, 1600, 1620, 1900, 1920, 2000, 2020
18.4---34 1650, 1880
18.4---38, 480/80R38 1650, 1875
540/80R38 1675, 1850
600/65R38 1850
Front (6.)
Track width
340/85R28, 380/85R28, 14.9R28, 1440, 1530, 1645, 1735, 1840, 1930, 2045, 2135
16.9R28, 420/70R28, 420/85R28, 440/65R28, 480/65R28,
480/70R28,
1440, 1530, 1645, 1735, 1840, 1930, 2045
520/60R28, 1435, 1530, 1640, 1735, 1835, 1930
540/65R28 1440, 1530, 1645, 1735, 1840, 1930
230/95R36 1505, 1580, 1600, 1700, 1880, 1980, 2000, 2100
14.9---24 1840, 1740
14.9---28, 400/80R28, 440/80R28, 500/65R28 1840, 1745
Measured between middle of tyres.
The front axle with suspension, the track widhts in front are 40 mm narrower.
The standard track widths are underlined. When track widths are adjusted or larger tyres fitted, the turning angles have
to be checked/adjusted with max turning angle of front axle on both sides. W hen adjusting the rear axle track widths,
check that the wheels rotate freely. Check also when using chains that the distance from the cab to the tyres does
not g o below 80 mm. Check further that the distance from parking lights to the outer sides of the tyres does not ex -
ceed 400 mm.
Fixed rims.
At the rear, the distance between the mudguards is 1090 mm. When using the narrow track widths for the rear axle, check that
the lower links do not touch the tyres. When required lock the side regulators.
IMPORTANT: According to EU directives, the smallest allowable gap between tyre and cab is 50 mm.
