23
7.2.1
SCHEMA CIRCUITO
ELETTRICO
Vedi schemi allegato 10.
NON SCAMBIARE
LA FASE CON IL NEUTRO.
LE LINEE ELETTRICHE DEVONO ESSERE
OPPORTUNAMENTE DISTANZIATE DALLE
PARTI CALDE DEL BRUCIATORE.
7.3
LUOGO D’INSTALLAZIONE
L’utente deve assicurarsi che l’installazione
sia conforme alle disposizioni locali vigenti
in materia. L’apparecchiatura deve essere
installata soltanto da personale qualificato,
il quale dovrà attenersi alle norme di
sicurezza vigenti nel luogo d’installazione.
Ogni operazione di manutenzione ordinaria
(per esempio il controllo delle tubazioni
d’alimentazione gas) e manutenzione
straordinaria (eventuale adattamento ad
un altro gas) devono essere eseguite
soltanto da personale qualificato.
Se il bruciatore non è installato
correttamente, può causare un incendio.
Per ridurre il rischio d’incendio, seguire le
istruzioni di installazione come riferimento
alla tabella
Tab. 7.3
Lapparecchio deve essere installato in un
locale ben aerato. Accertarsi che l’alusso
d’aria necessaria alla combustione sia
assicurato da una superficie minima
di 0.5 m
2
(zona inferiore del bruciatore).
Nel caso di rivestimento con pannelli
infiammabili, interporre materiale isolante
e rispettare rigorosamente le superfici
d’areazione sopra citate.
7.2.1
ELECTRICAL
CIRCUIT DIAGRAM
See diagrams in annex 10.
NEVER EXCHANGE
THE PHASE WITH NEUTRAL
THE ELECTRICAL LINES MUST BE
SUITABLY SPACED FROM HOT PARTS
OF THE BURNER
7.3
INSTALLATION SITE
The user must ensure that the installation
complies with relevant local legislation.
The equipment must be installed exclusively
by qualified personnel,
who must observe all current safety
standards in the place of installation.
Each routine maintenance operation
(such as checking gas supply pipelines) and
special maintenance
(e.g. converting to another type of gas)
must be performed exclusively
by qualified personnel.
If the burner is not installed correctly,
this may constitute a fire hazard.
To reduce the risk of fire, follow the
installation instructions and refer to table
Table 7.3
The equipment must be installed in a well-
ventilated area. Ensure that the air flow
required for combustion is guaranteed
by a minimum surface area of 0.5 m
2
(zone below the burner).
If the enclosure is made up of flammable
panels, insert suitable insulation material
and strictly observe the ventilation spaces
specified above.
