TOOLS REQUIRED
Page 2 of 9 RevA
Flat Head Screwdriver
Combination Wrenches:
1/2”, 9/16”, 14mm,
17mm, 19mm
3/8” Drive Ratchet w/ 4” extension
1/2”, 9/16” Deep Sockets
3/8” 12pt Socket, 1/4” Allen Socket
10mm, 19mm Socket
5/16 Nut Driver
Allen Wrenches:
1/4”, 5/32”, 3/16”, 5/16”
Torx: T45
Snap Ring Pliers
HARDWARE
14
8
9 6
10 11
5
12
13
7
15
16
SCALE 1:2
SHEET 2 OF 2
WT. LBS.
REV
PART #
SIZE
B
01
TITLE
UNLESS OTHERWISE SPECIFIED
INTERPRET DIMENSIONS
AND TOLERANCES
PER ANSI Y14.5M
THIRD ANGLE PROJECTION
MATERIAL
BRUSHED
SEE INDIV. DWGS
APPROVED
3/31/2022
DATE NAME
DRAWN
CHECKED
J. NATIVIDAD
DIMENSIONS ARE INCHES
TOLERANCES ARE:
FRACTIONAL: 1/16"
ANGULAR: 2
X.X 0.030"
X.XX 0.015"
X.XXX 0.010"
FINISH
HI OUTPUT SS 2-1 TOURING
SANTA FE SPRINGS, CA
BROWNSBURG, IN
www.vanceandhines.com
PROJECT
27321
M8 TOURING HI OUTPUT SS 2-1
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF VANCE & HINES AND SHALL NOT BE REPRODUCED, USED, OR
DISCLOSED TO OTHERS FOR MANUFACTURE OR FOR ANY OTHER PURPOSE, UNLESS SPECIFICALLY AUTHORIZED, IN WRITING, BY VANCE & HINES.
CAD
J. NATIVIDAD 3/31/2022
A A
B B
C C
D D
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
= CRITICAL FEATURE
