Camera settings

Check the box <Continue image upload> to upload the triggered images during

certain time or keep uploading until the trigger is off. Select <Upload for __ sec>

and enter the duration in the blank. The images of the duration will be uploading by

E-mail when the alarm input is triggered. The setting range is from 1 to 9999 sec-

onds. Select <Upload during the trigger active> to make the images keep being

uploaded to E-mail during the trigger active until the alarm is released. Set the Im-

age frequency as the upload frame rate. The setting range is from 1 frame to 15

frames.

NOTE: Make sure SMTP configuration has been completed. Refer to Mail for fur-

ther details.

 Send HTTP notification

Check this item and select the destination HTTP address. Then specify the pa-

rameters for event notifications by <Alarm> triggered. When an alarm is triggered,

the HTTP notification will be sent to the specified HTTP server.

For instance, if the custom parameter is set as “action=1&group=2”, and the HTTP

server name is “http://192.168.0.10/admin.php”, the notification will be sent to

HTTP server as “http://192.168.0.10/admin.php? action=1&group=2” when alarm

is triggered.

 Record to Video Clip

Select the item and the alarm-triggered recording will be saved into the microSD

card.

Pre-trigger buffer recording function allows users to check what happened to

cause the trigger. The pre-trigger buffer time range is from 1 to 3 seconds.

Select <Upload for __ sec> to set the recording duration after alarm is triggered.

The setting range is from 1 to 99999 seconds.

Select <Upload during the trigger active> to record the triggered video until the

trigger is off.

NOTE: Please make sure the local recording (with microSD / SDHC card) is acti-

vated so that this function can be implemented.
