Vanderbilt CCMS2010-IR/IRW User Manual

Camera settings
© Vanderbilt 2016
60
 90 Degree counter-/clockwise
Selecting <90 Degree Counter-/clockwise> will make the image 90° counter-
/clockwise inversed.
 180 Degree Rotate
Selecting <180 Degree> will make the image 180° inversed.
Click on <Save> to confirm the setting.
GOV Settings
Users can set the GOV length to determine the frame structure (I-frames and P-
frames) in a video stream for saving bandwidth. Less bandwidth is needed if the
GOV length is set to a high value. However, the shorter the GOV length the better
the video quality is. The setting range is from 2 to 64. The default value for H.264-1
/ H.264-2 / H.264-3 / H.264-4 is 60 / 60 / 30 / 30 (NTSC) or 50 / 50 / 25 / 25 (PAL).
Click on <Save> to confirm the GOV setting.
H.264 Profile
Users can set each H.264 Profile to <Baseline Profile>, <Main Profile> or <High
Profile> according to its compression needs. With the same bit rate, the higher the
compression ratio, the better the image quality is. The default setting is <Main Pro-
file>.
NOTE: Please make sure the higher compression ratio is supported by system be-
fore setup.
Click on <Save> to confirm the setting.
