Vanderbilt GM730 Installation Manual

008321_o 20
Appendix Anhang Annexe Appendice Anexo 附件 ［附件］
Additional UL requirements
1. Installation
For a complete safe and vault installation connect to ’high security cable’. This
product shall be installed in accordance with The Canadian Electrical Code, Part 1,
Safety Standard for Electrical Installations.
2. Programming - Sensitivity
 Remote input (terminal 7) must not be able to be activated manually. It has to
be assured that remote input is only active while functional noise requires its
activation.
 Remote input must not be activated permanently and is limited to 60 seconds.
2.1. Sensitivity settings verified by UL for Monolithic Concrete:
Minimum
thickness
Maximum
spacing
Mode and
operating radius
Shock
sensitivity *
0.6m
1.98ft
2.5m
8.2ft
Concrete 2.5m
High
4.0m
13.2ft
Concrete 4m
High
5.0m
16.5ft
Concrete 5m
High
 For coverage of surfaces over corners, the recommended spacing is reduced
by 75%.
2.2. Sensitivity settings verified by UL for Modular Steel Panels:
Minimum
thickness
Maximum
spacing
Mode and
operating radius
Shock
Sensitivity*
0.006m
0.25in
1.0m
3.3ft
Steel
1m
Low
1.5m
4.9ft
Steel
1.5m
Mid
2.0m
6.6ft
Steel
2m
Mid
 A detector shall be on each modular wall panel that is not continuously welded.
 For coverage of surfaces over corners, the recommended spacing is reduced
by 75%.
2.3. Sensitivity settings verified by UL for Steel Safes:
Placement
Minimum
thickness
Maximum
spacing
Mode and
operating
radius
Shock
sensitivity*
Body
0.006m
0.25in
1.0m
3.3ft
Steel
1m
Low
Door
Body
0.006m
0.25in
1.5m
4.9ft
Steel
1.5m
Mid
Door
Body
0.006m
0.25in
2.0m
6.6ft
Steel
2m
Mid
Door
 At least one detector is to be mounted on the door and at least one detector is
to be mounted on the body.
* Note: Shock sensitivity is defined as the sensitivity to single impacts on the detector
or its base. Only in USER MODE, the shock sensitivity can be set independently of
Mode and Operating radius with the help of the GMSW7 SensTool software. If one of
the fixed DIP setting is used, the shock sensitivity corresponds to Mode and
Operating radius as indicated in the tables above.
Requisiti supplementari dell'IMQ
Omologazione IMQ CA12.00766
1. Specifiche tecniche
Livello di prestazione
II° livello
Temperatura di funzionato
+5 ºC fino a +40 ºC
Grado di protezione
IP30
l’assorbimento di corrente
4 mA
immunità ai campi elettromagnetici10V/m−0.08
2 GHz
Accessori non sono coperti dalla certificazione:
 set da incasso
GMXW0
 scatola da pavimento
GMXB0
 scatola impermeabile
GMXWG0H
 Emisor de ensayo
GMXS1
 Generador externo de test
GMXS5
2. Accessori
Disposizione di prova GMXS1
I° livello
Piastra copritoppa GMXP3 GMXP3Z
I° livello
Exigences supplémentaires de NF&A2P
1. Fixation
Toutes les exigences relatives aux agréments nationaux et concernant l'application
du produit doivent être satisfaites.
2. Câblage du détecteur
Le câblage peut être réalisé avec du câble souple de 0,22mm ou du câble de type
SYT.
3. Accessoires
GMXD7 Feuille anti-perçage
Cette option n'est pas disponible en France.
GMXW0 Jeu pour encastrement mural avec couvercle
mode de protection selon (EN 60529)
IP51
capabilité max. de porter du couvercle
25 kg
GMXB0 Boite de sol
mode de protection selon (EN 60529)
IP51
capabilité max. de porter du couvercle
1000 kg
4. Caractéristiques techniques
Tension d'alim: 8,0 Vcc ....... 16 Vcc; ondulation résidu..: 0,25 Vac
Bande de fréquences :……………………………..…..13 à 19 KHz
protection du boîtier (EN 60529, EN 50102) ……………IP43, IK07
5. Certificat NF&A2P 3 boucliers N° 2730000350A0
Référentiel NF324-H58
GM730
273035-00
GMXS1
302302-02
GMXP0
302302-03
GMXW0
302302-08
GMXB0
302302-09
GMXC2
303303-02
GMSW7
273034-06
6. Organisme certificateur :
CNPP Cert.: www.cnpp.com
AFNOR Certification: www.afnor.org
Zusätzliche Anforderungen von VdS
1. Anwendung
1. Das Gerät eignet sich zum Einsatz in Einbruchmeldeanlagen nach
DIN EN 50131-1.
2. Die Einstellposition „Digitaler Filter“ in der Betriebssoftware SensTool darf nicht
verändert werden. Werkseinstellung: OFF
2. Programmierung
Wird der Steuereingang Klemme 7 “Remote“ zur Empfindlichkeitsreduktion benutzt,
so muss die Übereinstimmung mit den einschlägigen VdS-Vorschriften im
Systemzusammenhang geprüft, bzw. vom VdS akzeptiert werden.
