Appendix 2: Drill Template GMXP3/Z
64
Vanderbilt
Seismic Detectors Application Guide
I-200153-1
08.2016
12 Appendix 2: Drill Template GMXP3/Z
Scale 1:1
Dimensions when printed 88mm x 88mm
Printer settings must be optimized to reproduce at actual size.
While every effort has been made to ensure accurate sizing, the templates in this docu-
ment must be checked before use to ensure that the dimensions are correct.
