OWNER’S MANUAL
PARTS LIST
VYM27PR
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 20 of this manual.
KEY
NO. Part Number DESCRIPTION QTY.
1 104676-01 Log, Multi-Sided 1
2 103778-01 ODS Pilot (LP) 1
3 098249-01 ODS Nut 2
4 104592-02 Burner Outlet Tube 1
5 098264-02 Male Connector 1
6 102843-01 Burner Clip 1
7 099056-17 Burner Orifice Injector 1
8 104591-01 Burner 1
9 099387-13 Pilot Tube 1
10 103781-02 Gas Control Valve 1
11 104611-01 Lower Bracket 1
12 098304-01 Screw, #8 x .38 7
13 104590-01CK Painted Base Assy 1
14 098271-06 Ignitor Cable 1
15 102445-01 Piezo Ignitor 1
16 103587-02 Plate, Switch 1
17 103784-02 Flame Adjustment Knob 1
18 103784-01 Off-Pilot-On Knob 1
19 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4
20 103284-02 Wiring Harness 1
21 099998-01 Switch 1
PARTS AVAILABLE — NOT SHOWN
100563-01 Warning Plate 1
103877-01 Lighting Instructions Plate 1
100565-01 Warning Plate Fastener 1
100693-01 Caution Decal 1
101137-02 Hardware Kit 1
104310-05 Information Video 1
GA6060 Lava Rock 2
