PARTS LIST
This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions
listed under Replacement Parts on page 15 of this manual.
KEY PART NUMBER
NO. FB32CA NLFB32C DESCRIPTION QTY.
1 101872-03 101872-03 Firebox Top 1
2 101889-01 * Firebrick Retainer 3
3 101929-04 * Rear Firebrick 1
4 101932-04 * Side Firebrick 2
5 103207-01 103207-01 Outer Casing 1
6 103208-01 103208-01 Outer Shell Base 1
7 ** ** Firebox Wrapper 1
8 103297-01 103297-01 Assembly Screen 2
9 103217-01CK 103217-01CK Hood 1
10 103773-01 103773-01 Front Assembly 1
11 ** ** Firebox Bottom 1
12 103809-01 103809-01 Screen Rod 2
13 M12461-2 M12461-2 Screw, Outlet Mounting 1
14 101348-01 101348-01 Firebox Support 2
15 101357-01 101357-01 Outer Casing Top 1
16 M11084-26
____
Hex Head Screw, #10-16 49
____
M11084-26 Hex Head Screw, #10-16 46
17 103771-01 103771-01 Strain Relief Fitting 1
18 098304-01 098304-01 Phillips Pan Head Screw, #10 13
19 099230-01 099230-01 Hex Head Screw 3
20 099230-02 099230-02 Shoulder Screw 2
21 GA3555 GA3555 Duplex Outlet 1
22 103457-01 103457-01 Button Plug 1
*Not Included with Model NLFB32C
** Not available for field replacement.
