Vanguard V13 - STANDARD ITEMS SUPPLIED; SPECIFICATIONS

•
Over-spec componentry
•
Deep-gloss Pinot Noir finish
•
Polished nickel trim
•
Precision-cast Vanguard badge
•
100% Quality Control
•
5-Year Warranty
STANDARD ITEMS SUPPLIED
•
V13 Vacuum Tube Condenser Microphone
•
PS-13 Power Supply
•
VLSM Large Shockmount with aerospace-grade suspension rings
•
Padded Pinewood Microphone Storage Box
•
Locking Aluminum Carrying Case
•
7-Pin Braided Microphone Cable
•
Power Cable
SPECIFICATIONS
Capsule Type:
34mm / 3-micron Gold sputtered Mylar-True Condenser (DUAL CAPSULE)
Polar Pattern/s:
9 patterns selectable at power supply
Frequency Range:
20Hz-20,000 Hz
Output Impedance:
200 Ohms / transformer isolated
Maximum SPL :
144dB (0.5% THD @1000Hz) with pad engaged
Equivalent noise level :
Less than 13dB SPL (A-weighted)
Sensitivity:
-35dBV
S/N Ratio:
82dB (Ref. 1Pa A-weighted)
Output Connector:
Male XLR 7 pin
Included Accessories:
Padded Wooden Box, Shockmount, Metal case, Power Supply, 7-Pin Cable, Power
Cable
Vacuum Tube Type:
Proprietary Select Premium Grade
Power Requirement:
Dedicated PS-13 POWER SUPPLY w/ selectable 110/240V Capability
Finish:
Polished Nickel trim / Pinot Noir Body
Warranty:
5 Years
©2015 Vanguard Audio Labs, LLC. All rights reserved.
7
