Vansco Pro Series - Flow Chart

Y: STITCH OFF
0 TO 25“
Y: PAT TO OUT
A, B, Both, Neither
Y: OFF DELAY
0 to 50 ms
Y: ON DELAY
0 to 50 ms
Y: STITCH?
YES or NO
VOLUME GAIN
0 to 100
Change values while in RUN or
STOP mode, above this line.
Change values while in STOP
mode only, below this line.
YES
Y: OFFSET
0 to 99.9“
LSCO
000 TO 250
Y: START AT
0 to 99.9“
TEST OUTPUT A
ON or OFF
ALT ACCESS CODE
CURRENT CODE=???
TEST OUTPUT B
ON or OFF
VOLUME GAIN
0 to 100
CYCLE MODE:
SINGLE, REPEAT, NO PAT
Y: STOP AT
0 to 99.9“
TEST TRIGGER
ON or OFF
TRIGGER INPUT
NORMALLY OPEN/CLOSED
VOLUME MODE
AUTO or MANUAL
ACTIVE
A, B, Both
X: STITCH OFF
0 TO 25“
X: PAT TO OUT
A, B, Both, Neither
X: OFF DELAY
0 to 50 ms
X: ON DELAY
0 to 50 ms
X: STITCH?
YES or NO
YES
X: OFFSET
0 to 99.9“
X: START AT
0 to 99.9“
X: STOP AT
0 to 99.9“
X: PATTERN
Y: PATTERN
TEST
INPUT/OUTPUT
ERASE PROGRAM
1 to 4
SELECT PROG
1 to 4
STORED
PROGRAMS
DIGI-TRACK
SET UP
CONSTANTS
OUTPUT
SELECTION
X: STITCH OFF
0 TO 25“
Y: STITCH ON
0 TO 25“
VANSCO PRO SERIES
DIGI-TRACK Speed Compensating Control System
FLOW CHART
VANSCO
2652 LASHBROOK AVE
SOUTH EL MONTE, CA 91733
626-448-7611 FAX 626-448-0221
