Vantly E-6600 - Page 11

9
Assembly Instructions
STEP 7
Insert the Left Pedal Arm (H) to the Handlebar Post (D) and tighten using
6 Spring Washers (29) and 6 Allen Bolts (28). Place the back half of the
Left Pedal Arm (H) onto the top of Plastic Roller attached to the Steel
Plate Axel (N). Repeat the process above on the Right Pedal Arm (I).
H
29
28
29
28
29
28
I
D
