1 Introduction
1.1 Product Description
Vantron offers both ARM and ATOM based Single Boards Computer (SBC) platforms
including Cirrus LogicEP9315, RockChipRK3128, RK3368,RK3288,RK3399, Freescale
iMX6, iMX8, TI OMAP35xx CortexA8 series, and Intel Skylake and ApolloLake processor
boards. In additional to offering the standard SBCs, we also provide professional
customization board design services. Our seamless project management, efficient error-free
development process, strong fundamentals in technology, sufficient in human resources, and
on-time delivery will guarantee the success in your project development.
Based on idea of “Application Ready” products and services, our embedded computers
have embedded basic operation system which includes the drivers of its interfaces. So it is
easy to be used by adding your application software only. It can speed Time to Market of
your products, and saving more cost.
1.2 Connectors Description
This table is the respective describe valid signal of connector on Vantronboard.
Figure type:
N/C
Not connect
GND
Ground
/
active low signal
+
Positive of difference signal
-
negative of difference signal
Signal type:
I
Input
O
Output
I/O
input/output
P
Power or ground
A
Analog
OD
Open drain
CMOS
3.3 V CMOS
LVCMOS
Low Voltage CMOS
LVTTL
Low Voltage TTL
