3 x 2.5 KW. HEATING
6 WAY 35 AMP SOCKET
200 - 250 VOLT 50 or 60 Hz.
FOR ELECTRICAL LOADS AND POWER SUPPLY DETAILS
PLEASE REFER TO THE VAPANET LR & LHP INSTALLATION
OPERATION, MANUAL EDITION 2 OR LATER.
3 Phase & Neutral
plus Earth
Front
ELEMENTS
EMC Filter
"MASTER"
Earth
IF IN DOUBT ASK
75A
SSR-2
RATED
AT 20A.
RATED
Fuses
6 WAY 35 AMP PLUG
SSR-1
RATED
75A
68 RED
LZD-548
SUPPLY FROM
67 BLACK
LR10DP UNIT
BLUE
LZD-547 SHEET 1of3
SUPPLY TO
BLUE
RED
AC1 25A
CONTACTOR RATED
Front
IN DELTA FOR 200 - 250 V 3 PHASE
200 - 250 VOLT 50 or 60 Hz.
LR10D AND LR10DP HEATER ELEMENTS
POWER CONNECTION FOR CYLINDER 1
3 Phase plus Earth
VAPAC 10 KG/HR CYLINDER
6 WAY 35 AMP PLUG
3 x 2.5 KW. HEATING
ELEMENTS
Earth
6 WAY 35 AMP SOCKET
LR10D UNIT
AT 20A.
RATED
Fuses
RED
BLUE
SUPPLY TO
LZD-547 SHEET 1of3
BLUE
or LZD-548 SHEET 1of3
CONTACTOR RATED
AC1 25A
