Wiring Schematic Continued
Connect wiring harness as indicated below to the vehicles
electrical system:
• Red wire - Battery Positive
• Yellow wire - Ignition (+12v when ignition is “ON”)
• Orange wire - Positive +12v trigger from Alarm system
or courtesy light
• Black wire - Negative (ground), and momentary switch
/ LED indicator
When all LED lightbars are connected and installed
you can proceed to heat-shrink all connectors into
the ULX210 push button control and LED indicator.
Proceed to the “Operation of ULX210” section.
