Varec, Inc. 55
Chapter 5
Specifications
Liquid Level Indicator
Table 12: Liquid Level Indicator Specifications
Standard Installation Kits
Table 13: Standard Installation Kit Specifications
Standard Float Specifications
Table 14: Standard Float Specifications
Indicator Gaugeboards: Aluminum Alloy
Indicator Sight Target: Type 304 Stainless Steel and UHMW Polyethylene
Half Travel Sheave: UHMW Polyethylene
Float Cable: Type 316 Stainless Steel
Float Cable Clamp: Type 316 Stainless Steel
Float Tape/Cable (Elbow Drive Kit): Type 316 Stainless Steel
Gauge Float: Type 316 Stainless Steel
Mounting Brackets: Steel
Elbow Sheave Housing & Cover: 360 Aluminum
Elbow Sheave Wheel: Delrin
Top Anchor: Steel
Top Anchor Spring: Zinc Plated Steel
Bottom Anchor: Steel
Guide Cable: 3/32" Diameter Type 316 Stainless Steel
Material: Type 316 S. S.
Diameter: 14.5 inches (36.8 mm)
Eyelet Centers: 17 inches (43.2 mm)
Net Weight: 8.8 lbs. (3.99 kg)
