Vari Hurricane F-530 User Manual

Hurricane F-530
with leading wheel
8
are dry and the cutting blades are capable of crushing them into small pieces which need not
be removed from the surface. The maximum recommended height of swards emerged in the
same period when cut is up to 40 cm. This maximum height may decrease according to sward
density, moisture content and type.
The machine control is easier thanks to the leading wheel. The height adjustment (in
two positions) is made with a spacing tube, put on the pin of the wheel hinge.
Working width must be at all times accommodated to the density of the mown
sward.
4.2 Technical specifications.
Hurricane
F-530 unit value
Length (incl. handlebars) mm 1600
Width mm 620
Height (incl. handlebars) mm 1155
Weight kg 75
Maximum working width of the machine cm 53,3
Cutting height (
2 positions, measured on a solid
surface)
cm 5 , 8
Blade speed (at max. engine revolutions) min
-1
2481
Circumfential blade speed (at max. engine
revolutions)
m.s
-1
69,2
Travel speed (at max. engine revolutions) km.h
-1
2,17
Area performance of the machi
ne (according to
sward type)
m
2
/h max. 1000
Oil filling in the gearbox litre 0,5
Oil quality API GL - 4, GL – 5
SAE 90, 80W - 90
Engine type unit value
HONDA GCV 160
-- --
Cylinder volume cm
3
160
Bore x stroke mm 64x50
Max. performance at revolutions kW/rpm 4,1/3600 (5,5HP)
Max. torque at revolutions N.m/rpm 11,4/2500
Max. engine revolutions adjusted rpm 3200 (+/-100)
Fuel tank capacity litre 1,1
Petrol (unleaded) oct. no. 91-95
Oil filling litre 0,55
Oil API SJ/CF (SG/CD)
Spark plug -- NKG BPR6ES
-- BRISK LR15YC
