KC-435
9
Honda GX 35 engine
Displacement cm
3
35,8
Bore / Stroke mm 39 x 30
Max. engine revolutions min
-
1
10000
Engine revolutions at idle running min
-
1
3100 ± 200
Valve train system OHC
Cooling system air
Ignition system transistor
Power (according to ISO 8893) kW (HP) 1,0 (1,3) / 7000 min
-
1
Power (according to SAE J1995) kW (PS) 1,2 (1,6) / 7000 min
-
1
Fuel tank volume l (litre) 0,65
Oil volume in engine l (litre) 0,1
Fuel consumption g/kWh (l/h) 360 (0,71)
Spark plug NGK CMR5H
Table 4: Technical information on KC-435
1.3.2 Description of the machine and its parts
Brush cutter/trimmer
Brush cutter/trimmer:
1) Honda GX35 engine
9
2) Blade
3) Angular gearbox
4) Cutting tool cover
5) Shaft tube
6) Springing
7) Accelerator lever
8) Switch
9) Handle
Contents of the packing:
10) Brush cutter/trimmer
11) Cutting tool cover
12) Cover brim
13) Nylon head
14) Blade
15) Cap
16) Nut
17) Tubular box spanner with
Torx screwdriver
18) Hex key
Instructions for use – not in
the picture
Harness – not in the picture
Contents of the package
1.4 Instructions for use
1.4.1 Assembly of the machine
 Ask your dealer to unpack the machine and provide you with instructions as a part of the pre-sale
services!
 The right and left sides of the machines are meant as viewed from the operator’s place.
8
The area capacity of the machine depends on the type of the cut vegetation.
9
Description of the engine – see the separate instructions for use, part of the machine
