8
markings on the hub face.
on the hub face under the zinc anode. To return to original factory pitch settings, line up “AH” or “V” resp. “AS” or “R”
quarter turn ( 90° ) changes the pitch by ½” and a one full turn by 2” etc.. For a check of pitch adjustments there are markings
adjusting screws (2) & (4) in Figure 2 & 3a ( see pages 5&6 ) by half a revolution changes the pitch approx. 1“. That means a
It is quite possible to set the pitch continuously variable and independently for forward and reverse. The turning of the
Example for ahead:
The example shows adjustment of +1"
Marked with „ V “ !
Check adjustments ahead!
pitch has been increased ahead
Example for ahead:
markings line up
original factory pitch setting :
Marked with „ R “ !
Check adjustments astern!
The example shows adjustment of 1"
markings line up
original factory pitch setting :
pitch has been decreased astern
» 1” of pitch reduction / increase results in approx 200 engine revolutions increase / reduction
» If the engine exceeds the desired RPM increase the pitch
» If the engine does not reach the desired RPM reduce the pitch
Note:
