(6) Mounting Saddle
Connect the seat and seatpost first, then insert the seatpost into the bar receiver,
adjust its position and adjust the height to suit your riding habits, tighten the seat
with the clamp.
Note: Do not exceed the maximum saddle height and do not raise the saddle
above the safety line!
(7) Installation Of Tail Light/Rear Reflector
1.Installation Of Taillight
For C20-1/C26-2/C20-1 Pro Model E-Bike
Remove the taillight, install the taillight on the rack and tighten the screws
with a tool.
Connect the plug of the taillight cable and bind the cable to the shelf with a tie
wrap.
