4.2. Setting up the DMX mode
For the DMX addressing make sure that the channel 10 is on.
With all the other dipswitches you can set up your desired DMX address by using the binary system.
4.3. DMX channels
Channel 1 Dimmer Strobe
Channel 2 Red
Channel 3 Green
Channel 4 Blue
5. Technical data
Voltage 220V-240V 50Hz~60Hz
Power consumption 10W
Fuse 0,5A
For small Package For big package
Content 1 pcs Content 8 pcs
Measurements 19,5 x 14 x 14 Measurements 40 x 29 x 30
Weight 0,8kg Weight 6,5kg
