Model #: XL-1
Please call for replacement parts or assistance: 1-866-942-5362
VAS Furniture Mfg. Inc. Factory No. 55-12029 Page 3
Parts List
Please read completely through the instructions and verify that all parts listed
are present before beginning assembly.
A-Top Frame (1) B- Shelf Frame (1)
C- Bottom Frame (1) D- Long Spine (1)
D1- Short Spine (1) EL- Left Side Leg (1) ER- Right Side Leg (1)
F- Top Glass (1) G- Middle Glass Shelf (1) H- Bottom Glass Shelf (1)
I- Deluxe Bracket w/Mounting Plate (1) J- XYZ Mounting Frame (1)
K- Monitor Bracket (2) L- Safety Bar (1)
To Next Page
