Model #: XL-1
Please call for replacement parts or assistance: 1-866-942-5362
VAS Furniture Mfg. Inc. Factory No. 55-12029 Page 4
Hardware List
Please read completely through the instructions and verify that all parts listed
are present before beginning assembly.
(1)- Suction Cup (2)- 5/8” Bolt (3)- 3/4” Bolt (4)- 1 1/4” Bolt
(18+1 extra) (28+1 extra) (4+1 extra) (6+1 extra)
(5)- Stopper (6)- Nut (7)- Lock Washer (8)- Flat Washer
(2) (4+1 extra) (4+1 extra) (8+1 extra)
(9) - Concrete Anchor (6) (10) - Lag Bolt (6) (11) - Lag Bolt Washer (6)
Open Wrench (1) Allen Wrench (1) Tipping Restraint Hardware Kit (1)
(Inside Plastic White Bag)
TV Mounting Kit
M4 x 12 Bolt (4) M4 x 30 Bolt (4) M5 X 12 Bolt (4) M5 x 30 Bolt (4)
M6 x12 Bolt (4) M6 x 35 Bolt (4) M8x16 Bolt (4) M8 x40 Bolt (4)
M4 Lock Washer M5 Lock Washer M6 Lock Washer M8 Lock Washer
(4) (4) (4) (4)
Large Spacer (4) Small Spacer (4) M4/M5 Flat Washer (8) M6/M8 Flat Washer (4)
Tools Required: Allen Wrench (provided) and Open Wrench (provided), Phillips Screwdriver,
Mallet, Power Drill, 3/8” & 3/16”Drill Bit, Socket Wrench Adapter with Socket Set, 1/2”
Masonry Bit for brick concrete, Stud Sensor.
