OPERATING MANUAL 3300 DPF V6.4/20-EN
Page | 3
1. Technical data
Description
3300 DPF
Operating pressure
2-8 bar
Maximum pressure
8 bar
Container volume
1.250 ml
Connection thread Air
¼“
Compressed air supply
via quick coupling
Adjustable spray pattern
Material flow adjustable
Measurement
329 x 164 x 93 mm
Measurement cardboard
360 x 230 x 110 mm
Net weight
approx. 855 g
Gross weight
approx. 1.179 g
Weight 3900 WH 02/04
150 g *
Required air quality
filtered, condensate-free
* included with 3300 DPF-Set
2. Extent of delivery
Pressure cup gun, compressed air connection, operating manual
Additionally included with 3300 DPF set: Hose set 3900 WH 02/04
3. Intended use
This pressure cup gun is a compressed air operated quality tool for professional
use. It is suitable for processing liquid media in the form of loose containers.
4. Features
The effectiveness of the 3300 DPF pressure cup gun is based on overpressure.
For this purpose, pressure is built up in the pressure container by means of an
air duct integrated in the gun body. This conveys the material present in the
pressure container via a riser pipe to the material nozzle. When the lever is
pressed, the material flows out of the material nozzle where it is mixed with the
spray air.
5. Safety instructions
This pressure cup gun is not suitable for alkaline and acidic
media.
Such media must not be processed with this pressure cup
gun!!!
