Vehicle care 151
To replace the bulb on the left-hand
side, remove fuse box cover 3 165,
and also remove windscreen washer
system reservoir filler neck from
above. Washer fluid may escape if
the reservoir is full to the top.
Halogen headlights
Headlights have separate systems for
low beam 1 (outer bulb), high beam
2 (inner bulb) and daytime running
light/side light 3.
Low beam
1. Disengage wire clip and remove
protective cover 1.
2. Press base to the side and
remove bulb from reflector.
3. Detach plug connector from bulb.
4. Insert new bulb in reflector so that
the locating tab of the bulb holder
aligns with the reflector recess.
5. Engage bulb.
6. Attach connector to bulb.
7. Put on protective cover and
engage wire clip.
