IMPORTANT: Remove accessory from hose or telescopic extension tube before performing maintenance or
trouble shooting checks.
Removing blockages from the TurboTool*
Slide the locking ring
to remove.
Lift and separate
the housing.
Using a pair of scissors,
remove any threads
or hair caught around
the brushbar.
Line up the tabs on front of
housing and push together
to ret. Slide locking ring
into groove to secure.
TIP
To test for a blockage in hose,
drop a small ball of paper into the
hose. The paper will drop through
if the hose is clear.
Remove the hose from the vacuum
cleaner and telescopic extension tube.
Remove any blockage by inserting wire
coat hanger in to hose.
Removing a blockage from the hose
