operation
IMPORTANT: Maximum water temperature
50°C.
Fill the remaining space in the solution reservoir with
warm tap water. Replace the measuring cap (Fig 4/4).
NOTE: use only Vax AAASolution, using other cleaning
solutions may cause excessive foaming.
This may cause the float to shut of the cleaner
prematurely. Using other cleaning solutions will
invalidate your warranty.
Place the bottom of the solution reservoir into the
cleaner and push into place. There will be an audible click
when the reservoir is in the correct position (Fig 4/5).
Plug the cord into a mains electricity socket.
Turn the power switch on (Fig 4/6).
The switch is located on the back of the cleaner, next to
the handle release.
The power switch controls the vacuum motor. Press on
the handle release pedal and pull the cleaner back into a
reclined position (Fig 4/7).
IMPORTANT: Never leave the cleaner
unattended with the power on.
NOTE: Vacuum carpets thoroughly with dry vacuum
cleaner before washing.
Whilst depressing solution spray trigger, push carpet
washer in a forwards motion. Release trigger and pull unit
backwards in same path to remove dirty water and
solution from the carpet. (Fig 4/8).
Repeat if necessary, when the dirty water reaches the
max fill line on the dirty water tank empty the tank.
Fig.4/4
Fig.4/5
Fig.4/7
Fig.4/6
Fig.4/8
