Operation
---
Operation
Assembling your carpet washer handle
4
1
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
Locate locking pin and
press in points shown
to remove.
Insert handle and re-fit
locking pin.
Locking pin will ‘click’
when in place.
Press
2
Assembling your pre-treatment kit
Wrap solution tube
around holder for
storage.
‘Click’
1
2
Assembling your tool caddy and hose
Fit hose connector
end in first.
Wrap hose around
caddy tightly
anti-clockwise.
Clip in the last wrap of
the hose and wash
tool as shown.
Ensure locking
tabs are
horizontal.
Attach caddy to unit
top first.
Rotate tabs 90˚
clockwise to lock
caddy onto unit.
W90-RU & W89-RU Series User Guide v1.3.qxd:User guide 1/2/11 12:41 Page 4
Slide pre-treatment
wand holder onto
handle.
Place wand into holder
as shown
