1 Handle
2 Clean water tank release latch
3 Carry handle
4 Clean water tank
5 Dirty water tank release latch
6 Dirty water tank handle
7 Fixed brushbar
8 Dirty water tank
9 Dirty water tank lid
10 Power cord
11 Quick cord release
12 Handle release pedal
13 On/off switch
14 Upper cord clip
15 Solution release trigger
16 1 x Upper handle screw
17 2 x Right and left base screws
18 1 x Middle base screw
19 3 x Nuts
20
1 x V
ax AAA Carpet Cleaner 750ml
1. Diagram
P
arts Overview
2
Fig.1/1
1
2
3
4
5
6
8
7
9
16
17
18
19
15
14
10
13
11
12
20
