Vax Rapide Spruce V-022 User Manual

8
8. Brush Removal &
Replacement
WARNING: To reduce the risk of injury from moving
parts, unplug before servicing.
Tool Required: Phillips screwdriver
IMPORTANT: The plug must be removed from
electrical outlet before cleaning or maintaining the
carpet washer.
1. Remove the water tank switch off and unplug
carpet washer. Flip the cleaner on its side to
expose the nozzle base (Fig.8/1).
2. To remove the brush access cover, use a Phillips
screwdriver to remove the two (2) screws
(Fig.8/2).
3. Lift out the floating brushbar (Fig.8/3).
Fig.8/3
Fig.8/1
Fig.8/2
B
rush Removal & Replacement
4. Replace floating brushbar (Fig. 8/4).
5. Replace the brush access cover by inserting the
end furthest from the brush first. Then replace the
front end before securing in place with the two (2)
screws (Fig.8/5).
Fig.8/4
Fig.8/5
Vax V-022(Q).qxd 23/8/06 11:47 Page 8
