Vax V-028 User Manual

Fig.3/4: Insert the upper handle screw (as shown) and
tighten until secure.
NOTE: Make sure the power cord is out of the way to
avoid pinching.
BACK VIEW
Note: model
V-028M does
not have hose
wrap shown.
UPPER HANDLE
4
U
se & Function/Tool Caddy Assembly/Cord Storage
Fig.3/5
Fig.3/7
Fig.3/6
Fig.3/4
Caddy Assembly
(Model: V-028/V-028PT/V-028PET only)
Align tool caddy with screw holes on mid-section
and base.
Insert the three (3) tool caddy screws (as shown) and
tighten until secure.
Cord Storage
Wrap cord around
upper and lower
cord wraps as
shown in Fig.3/7.
Clip plug to cord to
secure for storage.
Upper Cord
Wrap
Lower Cor
d
Wrap with
Quick Cord
Release
Fig.3/3: Slide upper handle down onto unit.
Fig.3/3
Vax V-028 Range.qxd 27/4/07 13:26 Page 4

Vax V-028 Specifications

General

Brand	Vax
Model	V-028
Category	Vacuum Cleaner
Language	English
