REMOVING THE BATTERY
Insert the key into the lock and unlock the battery lock. Remove the key.
Open the frame lock and fold the bike.
Remove the battery.
Unfold the bike again.
INSERTING THE BATTERY
Open the frame folding mechanism and fold the bike.
Insert the battery with the connectors side last.
Unfold the bike and lock the frame folding mechanism.
Insert the key and turn it to lock or turn on bike settings.
BATTERY SPECIFICATIONS
48 V Battery
Battery: Rechargeable Li-ion battery pack
Model: ZLZCT13S6P175
Charging time: 5 hours
Voltage: 48 Volt
Battery cells: 65 cells
Initial capacity: 17.5 Ah
Operating temperature: -20 to +60 °C
Charging temperature: 0 - 45 °C
Storage time: 2 months
Storage temperature: 15 - 35 °C
Storage humidity: 50 (±25) %
The charger and battery supplied must only be used together and are not suitable for
other equipment.
