RECOMMENDED TORQUES
PART TORQUE (NM)
Front wheel bolt 28 - 32 Nm
Rear wheel bolt 30 - 35 Nm
Handlebar clamps 5 - 8 Nm
Adjusting nuts 12 - 15 Nm
Seat bolts 16 - 18 Nm
Brake cable bolt 12 - 15 Nm
Brake mounting bolt 12 - 15 Nm
Seat post nuts 16 - 18 Nm
Crank 35 - 40 Nm
Folding handle 6 - 8 Nm
Flange mounting screw 3 - 5 Nm
Rear derailleur 6 - 9 Nm
Sprocket holder screw 35 - 40 Nm
Gear change holder screw M5 5 - 7 Nm
Brake disc screw M5 20 - 22 Nm
Brake cable bolt 20 Nm
Support base 5 - 7 Nm
Battery connecting screw 5 - 7 Nm
Handbrake 5 - 8 Nm
DISPLAY ERROR MESSAGE
If an error occurs in the electrical system, the display will show an error code.
CODE FAULT
21 Power failure
22 Hand throttle fault
23 Motor fault
24 Motor fault
25 Brake fault
30 Communication fault
Declaration of Conformity: (See provided document).
Products marked with this symbol comply with all applicable community
regulations of the European Economic Area
26
