VC999 K2/K2N, K3/K3N 35
K2/K3 Grundplatte komplett / Bottom plate complete / Plaque de base complete
Bild Nr. 2
item No. K2 part No. K3 part No. Bezeichnung Designation Désignation
1 516.881 518.520 Grundplatte bottom plate plaque de base
2 516.839 --- Silikonprofil transparent L=1,4m silicone profile transp. L=1,4m profil silicone transp. L=1,4m
--- 516.839 Silikonprofil transparent L=1,7m silicone profile transp. L=1,7m profil silicone transp. L=1,7m
3 516.948 516.948 Schwenklager swivel bearing palier
4 500.042 500.042 Zyl.Schraube m.I-6kt.M6x16 cyl. screw M6x16 vis t cyl 6pc M6x16
5 501.319 501.319 Scheibe D=18/6,4x1,6 washer D=18/6,4x1,6 rondelle D=18/6,4x1,6
6 508.610 508.610 Flachkopfschr.m.Schlitz M8x20 sloted flat head screw M8x20 vis t plate à fente M8x20
7 518.132 518.132 Klemmenleiste 12polig terminal strip12 pol bornier 12 pôle
8 500.047 500.047 Zyl.Schraube m.Schlitz M3x20 cyl. screw M3x20 vis t cyl avec fente M3x20
9 501.666 501.666 Sechskantmutter M3 hexagonal nut M3 écrou M3
10 501.324 501.324 Scheibe D=7/3,2x0,5 washer D=7/3,2x0,5 rondelle D=7/3,2x0,5
11 501.709 501.709 Sechskantschraube M6x16 screw M6x16 vis t 6p M6x16
12 501.319 501.319 Scheibe D=18/6,4x1,6 washer D=18/6,4x1,6 rondelle D=18/6,4x1,6
13 504.028 504.028 Dichtung rubbergasket round joint
14 518.172 518.172 Kabelbaum K2/K3.. wire loom K2/K3 faisceau de câble K2/K3
15 518.443 518.443 Zuleitungskabel main cable câble d'alimentation
16 509.251 509.251 Kabelbride 1-Lappig cable strap bride
17 518.097 518.097 Senkschraube counter sunk screw vis t noyée
18 518.255 518.255 Warnschild 6-sprachig warning plate plaque d'attention
20 501.338 501.338 Vakuumschlauch vacuum hose tuyau à vide
21 501.140 501.140 Schlauchbride hose clamp bride pour tuyau
25 508.664 508.664 Zyl.Schraube m.I-6kt.M8x25 cyl. head screw M8x25 vis t cyl. 6pc 1M8x25
26 501.637 501.637 Scheibe D=16/8,4x1,6 washer D=17/8,4x1,6 rondelle D=17/8,4x1,6
30 518.054 518.567 Drehschieber-VP VGD10 / VCB20
230V 50/60Hz EW-Mot.ink.Kond.
vacuum pump VGD10 / VCB20
230V 50/60Hz
pompe à vide VGD10 / VCB20
230V 50/60Hz
30 518.318 518.569 Drehschieber-VP VGD10 / VCB20 200V
50Hz EW-Mot.ink.Kond.
vacuum pump VGD10 / VCB20
200V 50Hz
pompe à vide VGD10 / VCB20
200V 50Hz
30 518.319 518.319 Drehschieber-VP VGD10 / VCB20
100V 50/60Hz EW-Mo.i.Kond.
vacuum pump VGD10 / VCB20
100V 50/60Hz
pompe à vide VGD10 / VCB20
100V 50/60Hz
30 518.323 518.570 Drehschieber-VP VGD10 / VCB20
115V 60Hz EW-Mot.ink.Kond.
vacuum pump VGD10 / VCB20
115V 60Hz
pompe à vide VGD10 / VCB20
115V 60Hz
31 518.055 518.726 Kondensator 25mF zu VGD10 / VCB20 capacitor 25mF for VGD10 / VCB20 condensateur 25mF pour VGD10 / VCB20
31 518.300 518.727 Kondensator 130mF zu VGD10 / VCB20 capacitor 130 mF for VGD10 / VCB20 condensateur 130 mF pour VGD10 /
VCB20
