VC999 K2/K2N, K3/K3N 45
K2/K3 Schutzgas Option / Gas option / Option gas protecteur
Bild Nr. 7
item No. K2 part No. K3 part No. Bezeichnung Designation Désignation
1 509.729 509.729 Magnetventil 48V 50/60Hz solenoid valve 48V 50/60Hz électro-vanne 48V 50/60Hz
2 518.194 518.194 Schlauchtülle-L 6-1/8“ hose bushing L 6-1/8" raccord tuyau L 6-R1/8"
3 509.563 509.563 Reduziernippel doppel zyl. 1/8“-1/4“ reducing nipple double cyl. 1/8“- 1/4“ manchon de réduction double 1/8-1/4“
4 509.579 509.579 T-Stück 1/4“ T-piece 1/4“ pièce T 1/4“
5 518.195 518.195 Schlauchtülle 6 1/4“ hose bushing 6-1/4“ raccord tuyau 6-1/4“
7 518.331 518.331 Druckreduzierventil 0,8bar eingestellt pressure regulating valve 0,8bar adjusted régulateur 0,8bar fixe
9 501.157 501.157 Schnellentlüftungsventil fast air release valve soupape d'échappement rapide
10 518.195 518.195 Schlauchtülle 6-1/4" hose bushing 6-1/4“ raccord tuyau 6-1/4"
11 518.135 518.135 Ventilplatte valve plate plaque d'électro-vanne
12 508.382 508.382 Senkschraube m.Schlitz M4x10 countersunk-head screw M4x10 vis 6 noyée à fente M4x10
13 501.603 501.603 Zyl.Schraube m.I-6kt. M5x16 cyl. head screw M5x16 vis t cyl 6pc M5x16
14 501.318 501.318 Scheibe D=15/5,3x1,2 washer D=15/5,3x1,6 rondelle D=15/5,3x1,2
15 500.028 500.028 Sechskantmutter M5 hexagonal nut M5 écrou M5
16 501.147 501.147 Schlauchtülle 6-1/8" hose bushing 6-1/8" manchon plastique 6-1/8"
17 508.040 508.040 Winkelverschraubung 8/6-1/8" angle screwing 8/6-1/8“ raccord coudé 8/6-1/8“
18 501.135 501.135 Schlauch PA natur 8/6mm plastic hose PA 8/6mm tuyau polyamide PA 8/6mm
19 501.135 501.135 Schlauch PA natur 8/6mm plastic hose PA 8/6mm tuyau polyamide PA 8/6mm
20 501.135 501.135 Schlauch PA natur 8/6mm plastic hose PA 8/6mm tuyau polyamide PA 8/6mm
