VDO TEMPERATURE GAUGE User Manual

...ein Mannesmann-Unternehmen
VDO Kienzle Vertrieb und Service GmbH
04/97 
MONTAGEANLEITUNG
INSTALLATION INSTRUCTIONS INSTRUCTIONES
INSTRUCTIONS DE MONTAGE DE MONTAJE
Temperaturanzeiger Thermomètre
Temperature Gauge Termómetro
08 601 094
1-7
5
Technische Änderungen vorbehalten - Technical details subject to change - Sous réserve de modifications techniques - Quedan reservadas las modificaciones técnicas
4 - 20 mA
+ 
G
+ 
G
WK
+ 
G
WK= Warnkontakt
WK= warning contact
WK= Contact davertissement
WK= Contacto de aviso
12/24 V
12/24 V
12/24 V
Nur speziellen Geber 4-20 mA verwenden!
Use only 4-20 mA sensor.
Utiltsez uniquement un capteur 4-20 mA.

VDO TEMPERATURE GAUGE Specifications

General

Display Type	Analog
Housing Material	Plastic or Metal
Operating Voltage	12V
Temperature Range	-40°C to +120°C
Sender Unit Resistance	10Ω to 180Ω
Bezel Material	Plastic
Diameter	52mm
Power Supply	12V DC
Sensor Type	Thermistor
