The contra-angle is wrapped separately and
packed with the VDW.SILVER
®
. Refer to the
separate contra-angle operating instructions.
7.2. Preparation
1. Carefully remove the device and the acces-
sories from their packing and place them on a flat
surface.
2. Check that all the components listed in the
STANDARD COMPONENTS chapter 7.1. are present.
3. Check that the device serial number as read
on the bottom label of the central unit, the serial
number on the outer carton and the number
reported in the shipping documents are the same.
WARNING
Should any liquid exit from the device,
interrupt the installation immediately and
send the machine to an authorized service
center.
7.1. Standard Components
The VDW.SILVER
®
is supplied with the components listed below:
1) Central unit
2) Micromotor with cable and connector
3) Reduction gear contra-angle: VDW Endo 6:1 contra-angle
with accompanying operating instructions
4) Foot pedal with cable
5) External battery charger, model Cincon
Electronics Co. Ltd, TR30RAM120 with EU, UK, USA exchangeable plugs
®
