LVP605 User’s Manual http://www.cnledsourcing.com
---------------------------------------------------------------------------------------------------
LED VIDEO PROCESSOR
28
VGA/DVI Format 1024×768@60Hz/75Hz
1280×1024@60Hz/75Hz
1600×1200@60Hz
1920×1080p@50Hz/60Hz
1366×768@60Hz
1440×900@60Hz
2048×1152@60Hz
VGA Scope/Impedance
R、G、B = 0.7 V（p_p）/ 75Ω
Output Connectors VGA OUT：15pin D_Sub(Female)
DVI OUT1：24+5 DVI_I
DVI OUT2：24+1 DVI_D
Others
Control Panel Button,RS232
Power 100-240VAC 35W 50/60Hz
Operating Temp 5-40 ℃
Humidity 15-85%
Dimensions（Package）
166 mm (height) ×428mm (width) ×545mm
(length)
Weight（G.W.） 5.0 Kg
Weight（N.W.） 3.2Kg
Dimensions：
