LVP605 User’s Manual http://www.cnledsourcing.com
---------------------------------------------------------------------------------------------------
LED VIDEO PROCESSOR
6
recommended to use this port when
operating and setting LVP605).
DVI OUT1 /
DVI OUT2
2 same DVI digital graphic signal output,
it can be connected with external LED
transmission card or LED transmission
box
SDI / HDSDI（OUT）
1-channel digital video signal loop output
DVI Loop OUT
1-channel
computer DVI digital signal loop
output
4
）
Audio Output (AUDIO OUT)
Corresponds to the selected video input signal, output this
channel audio input signals.
5
）
Signals of other ports
RS232 serial communication port
3. Connection diagram
