46 C10 Alpha/Graphic MUX: Multiplexes Alpha and Graphic
control signals. Some of these signals actually come from
the Clock Subsystem. e.g. LATCH1! and LATCHOI.
46, 47
48 - C13 Yideo Combiner: Routes video information from
Alpha/Graphic MUX to internal connector (J13).
The Video portion of the SBC Block Diagram and Schematie is shown on the next
three pages.
