Analog output 2
Parameter
Description
Range
Default
2A 00
AO2: Configuration output signal:
0 = OFF
1 = loop 1
2 = loop 2
3 = dehumidify in 4 pipe systems
(max LP1 cooling and LP2 direct acting)
4 = manual override (0 – 100%)
5 = feedback of temperature input or set point
0 – 5
1
2A 01
AO2: Configuration of output signal, reverse or direct
0 = heating, reverse Y
H1
, Y
R1
1 = cooling, direct Y
C1
, Y
D1
2 = heating and cooling (2 pipe system), Y
H1
+ Y
C1
, Y
R1
+ Y
D1
3 = VAV function
If output signal = manual override:
Choose manual override steps
0 = 0…100%
1 = 0…10
2 = ON/OFF
If output signal = feedback
0 = temperature input loop 1 (acc IP00)
1 = set point loop 1
2 = set point loop 2
3 = humidity sensor (-H Version)
4 = analog input
0 – 4
0
2A 02
AO2: Minimum limitation of output signal
0 – Max %
0
2A 03
AO2: Maximum limitation of output signal
Min – 100%
100%
2A 04
AO2: Maximum limitation in standby mode
0 – 100 %
50%
2A 05
AO2: VAV function cooling output in heating mode
0…100%
50%
2A 06
AO2: Not used
ON, OFF
OFF
2A 07
AO2: Choose alarm
0 = no action
1 = TI1 low alarm active
2 = TI1 high alarm active
3 = TI1 low or high alarm active
4 = AI1 low alarm active
5 = AI1 high alarm active
6 = AI1 low or high alarm active
7 = Binary input alarm
8 = Any alarm active
0 - 8
0
2A 08
AO2: Action in case of alarm
OFF = close
ON = open output
ON, OFF
OFF
2A 09
Temperature feedback minimum temperature
-40…215 °C
0 °C (32 °F)
2A 10
Temperature feedback maximum temperature
-40…215 °C
50 °C
(122 °F)
