4
5.1 AC RECHARGE
During Recharge:
a) Never turn on while charging.
b) Make sure that the AC power source is 120 volts, 60 Hz.
c) After recharge – disconnect cord and wait 5 minutes before use.
FIGURE 2 - AC CHARGER
WARNING: Use the supplied AC recharge adapter; do not substitute. AC recharg-
ing requires the use of the included AC charger/adapter that supplies
12 volts DC.
1. Connect the AC charger to an AC power source.
2. Plug the adapter’s barrel connecter into the recharge port located near the handle.
3. Recharge for 15 hours maximum.
4. After recharge, disconnect the barrel connector from the recharge port and store the
adapter.
5.2 DC RECHARGE
a) Never turn on spotlight while charging.
b) Maximum charge - 5 hours
c) After recharge – disconnect cord and wait 5 minutes before use.
FIGURE 3 - DC CHARGER
Make sure the DC source (jump starter, battery pack, vehicle accessory socket, etc) is
12 volt DC. The DC source should be able to supply at least 10 amps at 12 volt DC.
WARNING: Use the supplied DC recharge adapter, do not substitute.
DC recharge requires the use of the supplied DC recharge adapter.
1. Connect the DC recharge adapter’s DC plug to a 12 volt DC source.
2. Plug the adapter’s connecter into the recharge port located on the back of the unit.
3. Recharge for 5 hours maximum.
4. After recharge, disconnect the barrel connector from the recharge port and store the
adapter.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vector VEC184POB and is the answer not in the manual?

Vector VEC184POB Specifications

Power IconPower
spotlight bulb voltage12 volt
spotlight bulb power100 watt
battery voltage12 volt
