3
Two recharge adapters are supplied with the spotlight. It is rechargeable from
either a 12 volt DC accessory outlet, or from any 120 volt 60 Hz AC outlet. This
permits recharge flexibility for use around home, business or in the field. 12
volt DC power is available from most vehicles, boats, jump starters and portable
battery packs. Vector has a variety of portable power products that would make
ideal companions.
2. FEATURES
• High-intensity, ultra-white, 100-watt halogen bulb
• Corded/cordless, powerful Quartz Halogen Spotlight for use whenever and
wherever you need light
• provides up to 20 minutes of continuous light (when fully charged)
• Includes biuilt-in area light located in grip
• Corded - plug into any 12 volt DC accessory outlet for extended use and charging
• Built-in utility work stand for garage, work bench and roadside repairs
• Take anywhere - use cordless or plug into 12 volt DC outlet
• Replace 12 volt, 3 amp, sealed, non spillable battery
• Powerful, prefocused, replaceable quartz halogen bulb in spotlight
• Recharge from home or vehicle (AC and DC adapters included)
3. LOCATION DIAGRAM
4. OPERATION
A two-position switch (spotlight on/off) controls the operation of the main beam. The
area light is controlled by a two-position button (area light on/off) is located on the side
of the unit. The spotlight can be continuously lit for up to 20 minutes on a full battery
charge. The area light can be lit for up to 12 hours on a full battery charge.
Figure 1 shows locations of the handle, the handle lock button, spotlight ON/OFF
switch, area ON/OFF switch, and the recharging port with LED charging indicator.
5. RECHARGING
AC and DC recharge requires use of these sup-
plied recharge adapters. Do not charge spotlight
using any other adapters (see Figures 2 and 3).
TRIGGER LOCK
SWITCH
LED CHARGING
INDICATOR
FOUR POSITION
HANDLE
AREA LIGHT ON/OFF BUTTON
BEAM ON/OFF TRIGGER
FIGURE 1
AREA LIGHT
RECHARGE PORT
DC CHARGING PORT
