1290K Instruction Manual AMRadio Transmitter
PARTS LIST
Your kit should contain all of the parts listed below. Please identify and
inventory each item on the checklist before you start building. If any parts are
missing or damaged, refer to the manual's warranty section for replacement
instructions. If you can't positively identify an unfamiliar item on the basis of
the information given, set it aside until all other items are checked off. You
may then be able to identify it by process of elimination. Finally, your kit will
go together more smoothly if parts are organized by type and arranged by
value ahead of time. Use this inventory as an opportunity to sort and arrange
parts so you can identify and find them quickly.
Resistors:
Q Qty Part Description Designation
1 15 ohm (brown-green-black) R2
1 1K ohm (brown-black-red) R3
14.7K ohm
(y
ellow-violet-red
)
R4
Ca
p
acitors:
Q Qty Part Description Designation
2 100 pF ceramic disc (101) C9,C10
1 510 pF polstyrene (510) C8
5 0.1 uF ceramic disc
(104)
C3,C4,C5,C6,C7
2 100 pF ceramic trimmer CI 1,C12
Semiconductors:
Q Qty Part Description Designation
1 4049 16-pin DIP integrated circuit U1
1LM386 8-
p
in DIP inte
g
rated circuit U2
Inductors:
[X] Qty Part Description Designation
1 22 uH molded choke (red-red-black) L2
2 100 uH molded choke (brown-black-brown) L7,L8
2 180 uH molded choke (brown-gray-brown) L5,L6
2 330 uH molded choke (orange-orange-brown) L4,L9
1 680 uH molded choke (blue-
g
ra
y
-brown) L3
