High Exhaust System
Temperature (HEST) Lamp
TIER 4 ENGINE ONLY
VeeCAN 320
TM
Diesel Particulate Filter (DPF) Lamps
Glow Plug Lamp
Regeneration Inhibit Switch/Lamp
Diesel Particulate Filter Lamp
Diesel Exhaust Fluid level
Lamp (Not Equipped)
Check Engine Lamp
Stop/Check Engine Lamp
Consult On Screen Prompt & Engine Manual
To Determine Severity Of Fault
Note: Please refer to engine manual for further information regarding actions required for
ECM Controlled engines & Tier 4 engines.
LOW FUEL
Regeneration Level Lamp - Indicates Status Of Exhaust Temp. During
Passive Regen (R.LOW-R.MED-R.HIGH)
TIER 4 ENGINE ONLY
TIER 4 ENGINE ONLY
TIER 4 ENGINE ONLY
ECM CONTROLLED ENGINE ONLY
ECM CONTROLLED ENGINE ONLY
ECM CONTROLLED ENGINE ONLY
Forced Regen Active -
RPM raises to 2000RPM
5-20minutes depending on
soot load
Soot level is above
limit - Park vehicle
and Perform forced
Regen
Soot Level -
low,med,high
