SI21 Solar Pump VFD Manual
17
A
0: Keyboard digital given frequency
1: Keyboard analog potentiometer given
2: Current/voltage analog AI given
3: Reserved
4: Reserved
5: Terminal pulse PUL given
6: RS485 communication given
7: Terminal UP/DW control
8: PID control given
9: Program Control (PLC) given
10: Option card
11: Multi-speed speed given
F01.09(0x0109
)
Keyboard
digital given
frequency
V/F SVC
Used to set and modify the keyboard digital
setting frequency.
50.00Hz
(0.00Hz～
upper limit
frequency
setting)
F01.10(0x010
A)
Maximum
frequency
V/F SVC
The maximum frequency that the frequency
converter can set.
50.00Hz
(upper limit
frequency～
600.00Hz)
F01.12(0x010C
)
Upper limit
frequency
digital setting
V/F SVC
The upper line frequency is given when F01.11
is set to 0.
0.00Hz
(0.00Hz～
upper limit
frequency
digital setting)
F01.13(0x010
D)
Lower limit
frequency
V/F SVC
Given a lower frequency limit, the given
frequency is limited.
0.00Hz
(0.00Hz～
upper limit
frequency
digital setting)
F01.22(0x0116
)
Acceleration
time 1
V/F SVC
The time required for the output frequency to
accelerate from 0.00 Hz to the time reference
frequency.
1s～65000s(F01.21 = 0)
0.1s～6500.0s(F01.21 = 1)
0.01s～650.00s(F01.21 = 2)
Model setting
(0.01s～
650.00s)
F01.23(0x0117
)
Deceleration
time 1
V/F SVC
The time it takes for the output frequency to
decelerate from the time reference frequency
to 0.00 Hz.
Model setting
(0.01s～
650.00s)
